Name: 5mm Pixel Pitch indoor Full Color Led Screen Smd3528 1/16 Scan Fixed Intallation
Brand: HJY

ISE Show P3.91 Indoor Curve DJ Booth Stage Video Wall Led Display 220/110V 1920Hz factory

Product Details:

Place of Origin:

China

Brand Name:

HJY

Certification:

CE FCC

Model Number:

P3.91

Payment & Shipping Terms:

Minimum Order Quantity:

1SQM

Packaging Details:

wooden case or flight case

Delivery Time:

15-20days after receiving deposit

Payment Terms:

T/T, Western Union, MoneyGram

Supply Ability:

3000sqm per month

Product Description

ISE show led display P3.91 indoor curve di booth stage rental led display

parameter name		P3.91
Module composition	Pixel structure	Surface mount three-in-one LED
	Pixel pitch (mm)	3.91
	Module resolution (W × H)	64×64dot
	Module size (mm)	250(W)× 250(H)
	Module max power consumption (W)	23w
Unit composition	Unit resolution (W × H)	128 × 256dot
	Unit size	500(W)× 1000(H)×80(D)
	Weight (kg / box; kg / ㎡)	13KG
	Pixel density (dots/㎡)	65536dot
	Box flatness (mm)	≤ 0.2
Optical parameter	Single point brightness	correction
	Single point color	correction
	Brightness (nits)	1400 adjustable
	Color temperature (K)	≥19000 (can be customized)
	Horizontal viewing angle ( °)	160
	Vertical viewing angle ( °)	140
	Optimum line of sight	≥5
	Luminous point center distance deviation	<3%
	Brightness uniformity	≥97%
	Chromaticity uniformity	±0.003Cx, within Cy
	Gray level (Bit)	16
	Maximum contrast	≥3000:1
Electrical parameter	Peak power consumption (W/㎡)	300
	Average power consumption (W/㎡)	210
	Power supply requirements	110~220VAC±10%
Processing performance	Drive mode	constant current drive
	Frame change frequency (Hz)	60
	Refresh rate (Hz)	≥ 1200
Using parameters	Typical life (hrs)	100,000
	Operating temperature range (°C)	-20~+50
	Operating humidity range (RH)	20%~90%

Advantages:
1) High refresh rate , high gray scale ,high contrast rate , perfect viewing effect.
2) Seamless connection and soft image.
3) Easy and fast installation without tools, and both for fixed installation and rental using,
4) Support hot-plug connection, and safety operation.
5) Aluminum die-casting cabinet, flatness and uniformity screen with cabinet difference controlling within 0.1mm and screen gap within 0.5mm.
6) Both for fixed installation and rental using, various installation condition.
7) Support point correction function, ensure the color and brightness consistency.
8) One cabinet with multi-purpose, product upgrading only need to change the module , low upgrade cost.

ISE Show P3.91 Indoor Curve DJ Booth Stage Video Wall Led Display 220/110V 1920Hz
