Quality Stage Rental LED Display & Outdoor Rental LED Display Manufacturer

Pixel Pitch 10mm Led Screen Stage Backdrop SMD3535 3 IN 1 1/4 Scan Waterproof factory

Product Details:
Place of Origin: CHINA
Brand Name: HJY
Certification: CE FCC
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Packaging Details: flight case for rental led display;wooden case for fixed led display
Delivery Time: 15-20 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000m²/month

Detail Information

Detail Information

Brightness: 7000cd/sqm Pixel Pitch: 10mm Pixel Configuration: 1R1G1B Density: 10000cd/sqm Led Chip: Smd3535 Scan Mode: 1/4 Scan Viewing Angle: 120/60 Life Span: 100000hours

Product Description

Product Description

SMD3535 3 IN 1 1/4 scan waterproof full color outdoor p10 rental led display

Item parameter
Pitch Size 10mm
Module Size 160*160mm
Panel Pixel 16*16dots
Pixel Configuration 1R1G1B
Color Scale 256-65536grade/16777216colors
Pixel density 10,000pixels/square meter
View angle(H/V) 120/60degree
Brightness ≥6500cd/square meter
View distance 5-150m
Power consumption 100-1200W/square meter
Net weight 60kg/square meter
Operating temperature —25°C~+60°C
Operating humidity 10%—95%RH
Lifetime ≥100,000hours
Exchange frame speed >150frames per second
Refresh frame frequency 600Hz
Control distance 100m (without relay), single-mode fiber:
20000m,multimode fiber:500m-20km
Power 110V/220V/380V±15% 50Hz
operating system Windows98/Me/2000/Xp
Drive mode constant current driving
display mode VGA640X480—VGA1600X1024
Protections for outdoor display IP65
Accepting signal PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI



product description



1. Excellent effect: Using dynamic scanning technology, the picture is stable, no noise, the image effect is clear, the animation effect is vivid and diverse, and the video effect is smooth and realistic;

2.rich in content: can display text, graphics, images, animation, video information;

3.flexible mode: the user can arbitrarily arrange the display mode;

4.the cabinet customization: the cabinet supports customized size;

5.excellent viewing angle: both horizontal and vertical have a large viewing angle, which is suitable for environments with wide horizontal distribution and large height difference;

6.High reliability: using distributed scanning technology and modular design technology, reliability and stability are higher;

7. quality assurance: the use of imported luminescent materials, high-quality IC chips, noise-free high-power power supply; tensile and shockproof, 10 years of long life;

8. easy maintenance: modular design, easy installation, and maintenance.



Pixel Pitch 10mm Led Screen Stage Backdrop SMD3535 3 IN 1 1/4 Scan Waterproof

Pixel Pitch 10mm Led Screen Stage Backdrop SMD3535 3 IN 1 1/4 Scan Waterproof

Pixel Pitch 10mm Led Screen Stage Backdrop SMD3535 3 IN 1 1/4 Scan Waterproof

our service

Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customers.
3. Provide unique and professional solutions based on customer's requirements.
4. Datasheet and samples offered.
5. Other required services such as special packing design, factory visiting and so on.

On-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.

After-sale service:
1. Complaint responds period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 24 months.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
