Name: 5mm Pixel Pitch indoor Full Color Led Screen Smd3528 1/16 Scan Fixed Intallation
Brand: HJY

1R1G1B Indoor Rental LED Display Small Pixel Pitch 1300 Nits / Sqm IP34 Front factory

Product Details:

Place of Origin:

shenzhen

Brand Name:

HJY

Certification:

CE FCC

Model Number:

P2.604

Payment & Shipping Terms:

Minimum Order Quantity:

negotiate

Packaging Details:

flight case

Delivery Time:

15-20 days after receiving deposit

Payment Terms:

T/T

Supply Ability:

1000sqm per month

Product Description

small pixel pitch led screen P2.604 indoor rental led display

Specifications:

No	Specifications
1.	LED chip	SMD 3IN1 1R1G1B
2.	Physical Pixel Pitch	2.604mm
3.	Physical Pixel Density	147456(dots/sqm)
4.	Pixel composition	1R1G1B
5.	Moduel Size	250*250mm
6.	Moduel resolution	96*96dots
7.	Cabinet thickness	0.85cm
8.	Bracket of cabinet	Easy to install and dismantle
9.	Brightness	1300cd/m2
10.	Colors	16.7millio
11.	Viewing angle	Horizontal 120°, Vertical 120°
12.	Viewing distance	3m -100m
13.	Soft Rubber Mask	To protect player and LED display itself .
14.	Scan frequency	1/32 scan
15.	Video Frame Rate	all forms
16.	Color temperature	6500°K to 9500°K adjustable
17.	Control method	synchronous control by PC or Asynchronous control
18.	Life span( half brightness)	≥100,000 hours
19.	Weight	8-16Kg/sqm
20.	IP rate	IP34 front
21.	Average power consumption	300W/sqm
22.	Peak power consumption	600W/sqm
23.	Input voltage	AC220V/50Hz ±10% or AC110V/60Hz ±10% AC380V/60Hz ±10%
24.	Operating Environment	Temperature:-20 - +60 Humidity:10%-95%RH
25.	Operating system	Windows XP/7/8/10
26.	Type of video signal	S-video, composite video ,RGB ,VGA ,DVI

1R1G1B Indoor Rental LED Display Small Pixel Pitch 1300 Nits / Sqm IP34 Front

1.Are your trading company or manufacturer?

We are one of the best Manufacturers which located in Shenzhen city of China.

We can provide the Best Solutions of LED Display!

2.What details need to be provided to get a quotation?

The buyer needs to provide pixel pitch,usage,dimension of screen and as more details as possible.

3. What are your terms of delivery?

We accept EXW,CIF,or Express (fast delivery).

Thank you for choosing our products! We are always trying our best to provide you the best quality product as well as the best service for you.
