Detail Information
|
Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | HJY |
| Certification: | CE FCC |
| Model Number: | P8 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | negotiation |
| Packaging Details: | wooden case outdoor led display supplier |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000sqm/month |
|
Detail Information |
Detail Information
Product Description
Product Description
outdoor led display supplier P8 front service fixed led display
Parameter:
| Pixel pitch | 8mm |
| Pixel configuration | 1R1G1B 3535 |
| LED type | 3-in-1 SMD 3535 |
| Module size | 320*320mm |
| Module weight | 2kg |
| Module resolution | 40*40 dots |
| Cabinet size | 1280*1280*200mm |
| Cabinet material | iron cabinet |
| Cabinet weight | 50kg |
| Ingress protection | IP65 |
|
Pixel density |
15625dots/m² |
|
Brightness |
≥6000 cd/m² outdoor led display supplier |
|
Viewing angle |
H≥160° V≥160° |
|
Min.viewing distance |
8m |
|
Max.power consumption |
1200W/m² |
|
Avg.power consumption |
600 W/m² |
|
Working voltage |
110~220VAC±15% |
|
Interface |
HUB75 |
|
Colors |
16.7millon colors |
|
Gray level |
14-16bits |
|
Frame frequency |
≥60frames/s |
|
Refresh rate |
≥300Hz |
|
MTBF |
≥100000 hours |
|
Lifespan |
≥75000 hours |
|
Protective function |
Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc. |
|
Operating temperature |
-10℃ ~ +40℃ |
|
Operating humidity |
10-80% no condensation |
|
Storage temperature |
-20℃ ~ +60℃ |
|
Storage humidity |
10-85% no condensation |
|
Video signal (with video processor) |
AV, S-video, VGA, DVI, YPbPr, HDMI, SDI, DP |
|
Color temperature |
Adjustable by software |
|
Brightness level |
256 levels, automatic adjustment by software |
|
Control way |
Computer, video-synchronous, real-time, off-line, wireless, internet, etc. |
1) New style module mast which can improve 10% brightness than normal module mask
and realize clearer images with a stronger feeling of layers
2) With Powerful and experienced engineers and technician team, with advanced production equipment, we control all steps from material to finished product,
from design to products that guarantee the quality and reliability.
3) Excellent quality that passes CE FCC with low power consumption, High
brightness, Long Lifespan, and easy installation
4) If you require for projects installation, our engineer can go to guide you on how to install the led screen.
5) Free training after order, and offer you the training course in detail.
6) The best competitive price at the market with the same even better quality.
