Name: 5mm Pixel Pitch indoor Full Color Led Screen Smd3528 1/16 Scan Fixed Intallation
Brand: HJY

led electronic display screen fixed outdoor led display P6 full color led display factory

Product Details:

Place of Origin:

China

Brand Name:

HJY

Certification:

CE FCC

Model Number:

Payment & Shipping Terms:

Minimum Order Quantity:

negotiable

Packaging Details:

wooden case

Delivery Time:

15-20 days after receiving deposit

Payment Terms:

T/T, Western Union, MoneyGram

Supply Ability:

1000 square meter per month

Product Description

led electronic display screen fixed outdoor led display P6 full color led display

Product Description

1	Pitch size	6mm
2	Module size	192mm*192mm
3	Module pixel(dots)	32*32 dot
4	Pixel configuration	1Red,1Green,1Blue SMD 3-in-1
5	Color scale	65536degree/1.07 billion colors
6	Pixel density	27777pixels/square meter
7	View angle(H/V)	60/120degree
8	Brightness	≥5000cd/sqm
9	Brightness adjustment	100level automatic or manual
10	View distance	6--80m
11	Power consumption	100-1200W/sqm
12	Net weight	45kg/square meter
13	Operating temperature	—45°C~+60°C
14	perating humidity	10%—95%RH
15	Life time	≥100,000hours
16	Out of control dot	≤3/10,000
17	Whole Display Flatness	≤1mm Juncture
18	Exchange frame speed	>150frames per second
19	Refresh frame frequency	600Hz
20	Control distance	Cat. 5: 120m (without repeater), single mode fiber:20km,multi mode fiber: 500m
21	Power	110V/220V±15% 50Hz
22	Operating system	Win7 Win8 Win10
23	Drive mode	1/8 scan
24	Display mode	VGA640X480—VGA1600X1024
25	Protections for outdoor display	IP65 for front, IP54 for rear
26	Maintenance way	rear access, hanging installation
27	Accepting signal	PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

our led electronic display screen fixed outdoor led display P6 full color led display more details:

Working voltage :220/110V 50/60Hz
MAX.Consumption ;850W/square meter
AVE.Consumption ;250-420 W/square meter
Display mode ;(Normal)1024*768,800*600
Control system: CPU Pentium 4 or above
Operating system :Windows 7/8/10
Control way :Asynchronous or Synchronous is available

led electronic display screen fixed outdoor led display P6 full color led display
